Pure mechanical operation. No battery, no motor, no maintenance cost — just a well-built hydraulic stacker.
Available models: CTY-0.5 / 1 / 1.5 / 2 / 3 t
Standard specifications. Dimensions, capacity and lifting height can all be customised — tell us your requirements and we will quote accordingly.
| Parameter | Value |
|---|---|
| Rated load | 500 / 1000 / 1500 / 2000 / 3000 kg |
| Lift height | 1600 mm |
| Fork length | 800 / 900 mm |
| Fork adjustment range | 160–580 mm |
| Turning radius | 1450 – 1600 mm |
| Overall height (fork lowered) | 1940 – 2050 mm |
| Service weight | 100 – 240 kg |
Send us your load weight, lifting height and aisle width. We will confirm the right configuration and send a quotation within 24 hours.
Complete specifications supplied with each model.
| Parameter | Unit | CBD20 | CBD30 |
|---|---|---|---|
| Drive type | Electric | ||
| Driving style | Walking | ||
| Rated load | 2000 | 3000 | |
| Load centre distance | 500 | 500 | |
| Lift height | 200 | 200 | |
| Fork spread, outside | 550/685 | 550/685 | |
| Dimensions | 1730*685*1540 | 1730*685*1540 | |
| Fork dimensions | 55*160*1150 | 55*160*1150 | |
| Ground clearance, min. | 85 | 85 | |
| Turning radius | mm | 1200 | |
| Min.Right Angle Channel Width | 1560 | 1560 | |
| Tyre type | Rubber Tires | ||
| Drive Wheel Size | 350x100 | 350x100 | |
| Loading wheel size | 80x70 | 80x70 | |
| Travel speed,full/no load | 3.5/4 | 3.5/4 | |
| Lifting speed,full/no load | 4 | 4 | |
| Max.Climbing Capacity | 15 | 15 | |
| Battery Voltage/Rated Capacity | 2*24/20(32) | 2*24/20(32) | |
| Drivemotor | 0.8 | 0.8 | |
| Liftingmotor | 0.8 | 0.8 | |
| Battery Size | 159*188*104 | 159*188*104 | |
| Self-weight | 225 | 265 |
