Legless design — no outriggers, so it loads straight onto trucks and handles closed-bottom pallets.
Available models: ZPD (walking & riding)
Standard specifications. Dimensions, capacity and lifting height can all be customised — tell us your requirements and we will quote accordingly.
| Parameter | Value |
|---|---|
| Rated load | 1000 / 1500 / 2000 kg |
| Load centre | 500 mm |
| Lift height | 1600 – 3500 mm |
| Overall length | 2650 / 3050 mm |
| Fork ground clearance | 50 mm |
| Tyre | Polyurethane |
| Drive motor | 1.5 kW |
| Lift motor | 2.2 kW |
Send us your load weight, lifting height and aisle width. We will confirm the right configuration and send a quotation within 24 hours.
Complete specifications supplied with each model.
| Parameter | Unit | CPD15R | CPD20R |
|---|---|---|---|
| Drive type | Electric | ||
| Driving style | Station Driving | ||
| Rated load | 1500 | 2000 | |
| Load centre distance | mm | 500 | |
| Self-weight(with electric battery) | 2030 | 2030 | |
| Wheels | PU | ||
| Wheel size，Rear wheel ，Front/rear quantity | φ200*100 | ||
| Turning radius Lifting speed，/ Travel speed，/ | mm | 1600 | |
| Gradeability，/ Battery voltage/ | 8/15(6/10) 24/280 | 8/15(6/10) 24/280 |
