Forks rotate 180° and shift sideways — one truck works both sides of a very narrow aisle.
Available models: Three-way series
Standard specifications. Dimensions, capacity and lifting height can all be customised — tell us your requirements and we will quote accordingly.
| Parameter | Value |
|---|---|
| Rated load | 1000 / 1500 kg |
| Lift height | Up to 12000 mm |
| Fork rotation | 180° |
| Aisle width | From 1600 mm |
| Camera | Standard |
Send us your load weight, lifting height and aisle width. We will confirm the right configuration and send a quotation within 24 hours.
Complete specifications supplied with each model.
| Parameter | Unit | CPCD10 | CPCD15 |
|---|---|---|---|
| Drive method | Electric | ||
| Driving Style | (Station Driver) | ||
| Rated load | 1000 | 1500 | |
| Load center distance | 500 | 500 | |
| Self-weight | 4800 | 5350 | |
| Wheels | PU | ||
| Gantry closing height | 3180 | ||
| Freelitingheight | 1980 | 1980 | |
| Liftheight | 6000 | 6000 | |
| Overhead guard height | 2280 | ||
| Body length | 3780/2850 | 3980/3100 | |
| Width ofanti-collision guard rail | 1500 | 1600 | |
| Forksize | 1070*122*40 | 1070*125*45 | |
| Forkadjustment size | 260-600 | 260-650 | |
| Channel rail height Minimum tumingradius | mm Wa(mm) | 120 | |
| Drive motor output | 6.5 | 6.5 | |
| Lift motor output Battery type Battery voltage/Capacity | 7.5 Lead Acid48V/400AH Communication | 8.6 Lead Acid48V/400AH Communication |
