Operator rises with the platform — man-up order picking in VNA racking.
Available models: Picker series
Standard specifications. Dimensions, capacity and lifting height can all be customised — tell us your requirements and we will quote accordingly.
| Parameter | Value |
|---|---|
| Rated load | 1000 / 1200 kg |
| Lift height | Up to 12000 mm |
| Fork rotation | 180° |
Send us your load weight, lifting height and aisle width. We will confirm the right configuration and send a quotation within 24 hours.
Complete specifications supplied with each model.
| Parameter | Unit | OPDS15/6.5m | OPDS15/8m | OPDS15/9.2m | OPDS15/10.5m |
|---|---|---|---|---|---|
| Drive type | Electric | Electric | Electric | ||
| Carying capacity | 1500 | 1500 | 1500 | 1500 | |
| Load center | 600 | 600 | 600 | 600 | |
| Weight(with battery) | 7705 | 8105 | 8405 | 8805 | |
| Tiresize,front | 380*192 | 380*192 | 380*192 | 380*192 | |
| Tire size,rear | 400*160 | 400*160 | 400*160 | φ400*160 | |
| Tire Type | PU | PU | PU | ||
| Wheelbase in front | 1362±10 | 1362±10 | 1362±10 | ||
| Wheel,number of frontand rear | 2/1x | 2/1x | 2/1x | ||
| Heightof gantry closure | 3745±20 | 4498±20 | 5098±20 | ||
| Lift height | 4760 | 6260 | 7460 | ||
| Overall height,highest position of thegantry | 7428±20 | 8928±20 | 10128±20 | ||
| Height of roofrack | 2564±20 | 2564±20 | 2564±20 | ||
| Platformheight | 442±10 | 442±10 | 442±10 | ||
| Auxiliarylifting height | 1740 | 1740 | 1740 | ||
| Platform heightafter upgrade | 5202±20 | 6702±20 | 7902±20 | ||
| Overall length | b1/b2(mm) | 1210/1555 | 1210/1555 | 1210/1555 | |
| Forksize | 40*120*950 | 40*120*950 | 40*120*950 | 40*120*950 | |
| Width offorklift | 908 | 908 | 908 | ||
| Width acrossforks | 870 | 870 | 870 | ||
| Pitch of guidewheel | 1630 | 1630 | 1630 | ||
| Lateral reach | 1300±20 | 1300±20 | 1300±20 | ||
| Ground clearance at bottomofgantry | 80 | 80 | 80 | ||
| Working channel width,0.8m*12m | mm | 1680 | 1680 | 1680 | |
| Turningradius | mm | 2220±20 | 2220±20 | 2220±20 | |
| Total ifting height | h3+h9(mm) | 6500 | 8000 | 9200 | |
| Max.pickingheight | h12+1600(mm) | 6802±20 | 8302±20 | 9502±20 | |
| Liftingspeed,full/no load | 280/300 | 280/300 | 280/300 | 280/300 | |
| Descent speed,full/no load | 320/300 | 320/300 | 320/300 | 320/300 | |
| Movementspeed,ful/noload | 190/200 | 190/200 | 190/200 | 190/200 | |
| Voltage/Rated Capacity | 80/560 | 80/560 | 80/560 | 80/560 |
